- 7 -
current outputs for transformers
5 – L3 output (–)
6 – L3 output (+)
7 – L2 output (–)
8 – L2 output (+)
9 – L1 output (–)
10 – L1 output (+)
20 – pulse output (+)
21 – pulse output (–)
If the secondary circuit of the transformer is opened
during operation, there is a risk of high voltage on the
secondary winding. In order to protect personnel opera-
ting the device, it is recommended to ground one end of
the secondary winding of each transformer.
1. Disconnect the power supply.
2. The indicator mounted on a rail in the distribution box.
3. Using a screwdriver, remove the screws and remove the front
shield meter terminals.
4. Connect the voltage-controlled phase, following the indica-
tions to terminals 1 (L1), 2 (L2), 3 (L3).
5. N-wire connect to terminal 4.
6. Transformers fasten on the phase conductors and secondary
outputs connected in accordance with the indications to the
terminals: 10-9 (L1), 8-7 (L2), 6-5 (L3).
Mounting
