F&F LE-02d CT User Manual

- 9 -
indication range dependent on gear
constant dependent on gear
current consumption signalling 3× red LED
read-out signalling red LED
pulse output
type open collector
maximum voltage 27 V DC
maximum current 27 mA
pulse time 35 ms
working temperature -25÷55°C
terminal 16 mm² screw terminals
dimensions 4,5 module (75 mm)
mounting on TH-35 rail
ingress protection IP20
The method of data projection depending on the gear settings:
Format Ip current
000000.00 5; 25; 40; 50; 60.
0000000.0
75; 80; 100; 120; 150; 200; 250; 300; 400;
500; 600.
00000000
800; 1000; 1200; 1500; 1600; 2000; 2500;
3000; 4000; 5000; 6000
