F&F LE-03MW CT User Manual

LE-03MW CT – user manual
6
4.3. Data displayed on the LCD
Page
Parameter
Unit
Symbol
Format
1
Date
XX-XX-XX
2
Time
XX-XX-XX
3
Total active energy consumption
kWh
6+2 000000.00
4
T1 tariff – active energy consumption
kWh
T01
6+2 000000.00
5
T2 tariff – active energy consumption
kWh
T02
6+2 000000.00
6
T3 tariff – active energy consumption
kWh
T03
6+2 000000.00
7
T4 tariff – active energy consumption
kWh
T04
6+2 000000.00
8
Total reactive energy consumption
kVarh
6+2 000000.00
9
T1 tariff – reactive energy consumption
kVarh
T11
6+2 000000.00
10
T2 tariff – reactive energy consumption
kVarh
T12
6+2 000000.00
11
T3 tariff – reactive energy consumption
kVarh
T13
6+2 000000.00
12
T4 tariff – reactive energy consumption
kVarh
T14
6+2 000000.00
13
L1 – Phase voltage
V
L1
3+1 000.0
14
L2 – Phase voltage
V
L2
3+1 000.0
15
L3 Phase voltage
V
L3
3+1 000.0
16
L1 – Phase current
A
L1
4+2 0000.00
17
L2 – Phase current
A
L2
4+2 0000.00
18
L3 – Phase current
A
L3
4+2 0000.00
19
Total active power
kW
5+3 00000.000
20
L1 – active power
kW
L1
5+3 00000.000
21
L2 – active power
kW
L2
5+3 00000.000
22
L3 – active power
kW
L3
5+3 00000.000
23
Total apparent power
kVA
5+3 00000.000
24
L1 – apparent power
kVA
L1
5+3 00000.000
25
L2 – apparent power
kVA
L2
5+3 00000.000
26
L3 – apparent power
kVA
L3
5+3 00000.000
27
Total power factor
1+2 0.00
28
L1 – power factor
L1
1+2 0.00
29
L2 – power factor
L2
1+2 0.00
30
L3 – power factor
L3
1+2 0.00
Warning!
The meter records absolute values of power and power factor.
