A-5 ENGLISH
F&P 950 Respiratory Humidifier setup
Attach the power cord and power cord retainer to the heaterbase�
Power cord retainer
The power cord retainer prevents the
power cord from accidental
disconnection� Required screw torque:
0�8 ± 0�3 Nm�
Power cord
Mounting bracket
Heaterbase
Attach the sensor cartridge to the heaterbase�
1
2
3
WARNING
The heaterbase must be mounted on an equipment mount capable of supporting
4 kg� Failure to comply may result in damage to the equipment mount and
heaterbase and potentially cause serious patient harm�
NOTE: Ensure the heaterbase does not block access to the power supply outlet�
