Description and Technical Data
7.d - Wheel units
- The wheel units are dened as follows
(g. “14“):
“front wheel”
“rear wheel”
The units consist of:
- hub;
- sprocket set (or cog-set) (rear hub only);
- brake disk;
- spokes;
- wheel rim;
- wheel rim cover strip;
- tyre;
- inner tube with valve;
- wheel reectors (optional);
- front mudguard (for “Living“ only);
- rear mudguard (for “Living“ only).
7.e - Electrical devices
- For information about the components of the
electrical power-assisted pedalling system and
how to use them, see Section “06”.
The bicycle can be equipped with
two types of pedal-assist control
instruments.
Check which model is
installed on your bicycle and see
the relevant instructions.
• Instrument “A”
• Instrument “B“
7.f - Battery pack
- The battery pack must be installed in the ded-
icated supported mounted on the frame. For
reasons of safety, the battery pack may be
secured to the support using one of the keys
supplied with your bicycle.
The battery pack is supplied complete with a
battery charger and connection cable.
