Assembly and Adjustments
- Align the tip of the saddle so that it is pointing
towards the from of the bicycle.
- Re-tighten the saddle support tube locking
collar (MAX tightening torque 8 Nm).
(g. “34“)
3.a - Regulating the saddle position
and angle
- Loosen the saddle locking screws (using a 6
mm Allen key) (g. “35“).
- Adjust the angle of the saddle as desired (g.
“36“).
- Tighten the screws respecting the correct
torque values
(see paragraph “4” - Section “03”)
(g. “37“).
4. ADJUSTING THE BRAKE LEVERS
- If you wish to adjust the position of the brake
levers:
The procedure described below is valid for
both brake levers.
· Loosen the lever locking screw (using a 5
mm Allen key) (g. “38“).
· Adjust the angle of the lever as desired (g.
“39“).
· Tighten the screws respecting the correct
torque values (see paragraph “4” - Section
“03”) (g. “40“).
5. ADJUSTING THE GEAR
CHANGE LEVER
- If you wish to adjust the position of the gear
change lever:
· Loosen the lever locking screw (using a 5
mm Allen key) (g. “41“).
· Adjust the angle of the lever as desired (g.
“42“).
· Tighten the screws respecting the correct
torque values (see paragraph “4” - Section
“03”) (g. “43“).
