FAR DGV18CH - Bracket Installation Method

ENGLISH
GB-24
(A) Sealing strip
(B) BRACKET
(C) SCREW
1. Place the bracket
(B) on the holes that
correspond to the size
of the screws. ere is
a set of screws for the
holes in each corner of
the hob (H). Lightly
tighten one screw (C)
through the bracket
(B) so that the bracket
attaches to the hob but
in such a way that the
hob can still be adjusted.
2. Put the hob back in
place and then gently
lower it into the
opening you have cut
into your worktop.
3. Under the hob, adjust
the brackets to the
appropriate position
for your worktop. en
retighten the screws
completely (C) to secure
the hob in position.
B
C
A
