ENGLISH
9
HOW TO OPERATE
CHOOSING A LOCATION
Select a level surface that provides enough open space for intake/outlet vents. A minimum of 3
inches (7.5 cm) is required between the oven and any adjacent walls. One side must be open.
1. Leave a minimum clearance of 12 inches (30cm) above the oven.
2. Do not remove the legs from the bottom of the oven.
3. Blocking the intake and/or outlet openings can damage the oven.
4. Place the oven as far away from radios and TV as possible. Operation of
microwave oven may cause interference to your radio or TV reception.
Plug your oven into a standard household outlet. Be sure the voltage and the frequency is the
same as the voltage and the frequency on the rating label. WARNING – Do not install oven over
a range cook-top or other heat-producing appliance. If installed near or over a
heat source, the oven could be damaged and the warranty would be void.
AFTER PLUGGING IN
As soon as the microwave is plugged into the outlet, the screen will display
"00:00" and the buzzer will ring once.
SETTING THE CLOCK
• While the LED Display reads "00:00", press and hold "CLOCK/TIMER" for
3 seconds to set clock. This unit has a 12-hour clock.
• Touch "CLOCK/TIMER" or “START/+30Sec.” to nish the clock setting.
•
NOTE: If the clock is not set, the current time will not display when powered.
CONTROL PANEL
KITCHEN TIMER
1. Touch "CLOCK/TIMER" once and the screen will display "00:00".
2. Press the number pads to enter time.(0:01-99:99).
3.
4. When the timer is done, the buzzer will ring 5 times and
the display will show the current time.
NOTE
When the number blinks, press the number pads to enter clock time. (01:00-12:59)•
The clock will display current time and ":" will blink.
