A.4.8. Calibration Mechanism
The calibration mechanism is positioned between the
hoppers and the seed pipes connected to the coulters
and hence they are used to determine the seed to be
delivered to the coulters during calibration. In this way, it
allows the seeding norm (amount of seed and fertilizer
to be spread) that will be applied to be properly and
easily measured during seeding.
Calibration Mechanism in the Model with
Fertilizer
Calibration Mechanism in the Model
without Fertilizer
For information on the use of calibration mechanism: (Refer
to .C.1. Seed and Fertilizer (Spread Amount) Spread norm
Adjustment:
C.1.1. Switching the Funnel Trays to
Calibration Position)
