Step 2: Preparing sump
A. Locate the lowest point of the fuel tank, which is typically below the fac-
tory fuel module. On some applications there is a dimple you can use for a
center point reference and it has the flattest surface for sealing the sump.
B. Using the center point, drill a small hole to drain the remaining fuel. Rec-
ommend having a container large enough to retain the remain fuel. Allow
fuel to drain completely.
C. Drill out a 2 3/4” hole using the center point and a hole saw.
D. De-burr hole and remove all shavings.
E. Place sump (SP-5500) into place, using 1 of the 10 mounting holes in the
sump drill 1 hole smaller than the 1/4” bolts. This will allow temporary
placement of 1 bolt.
