FASTBIND PUREVA XT USER MANUAL | v 1.0 | © Maping Co 2014
5
DRAFT
5
8
12
13
12
7
6
4a
1b
1c/ 1d
1e/ 1f
3a
1a
2
3
1
3b
3c
3e
3d
4b
4
9b
9a
10
11
9
8b
14
1 Positioning deck
1a Positioning deck
1b Nipping cams
1c/1d
Nipping tool back (soft cover/ hard cover)
1e/ 1f
Nipping tool front (soft cover/ hard cover)
2 Turn table handle
3 Press clamp turn table
3a Clamp handle
3b Support rod
3c Paper guide for soft and hard covers
3d Turn table front plate
3e Fastening holes for paper guide
4 Temperature control panel
4a Indicator lights
4b Temperature selection button
5 Front heat shield
3. maIn ParTs and conTrols
6 Storage tray
7 Cap hook
8 Thermal casing
8b handling lid
9 Fume extraction hood
9a Light switch
9b Bypass valve
10 Applicator handle
11 Roughening handle
12 Glue cartridge gripper
13 Storage locker
Figure3-1Mainpartsandcontrolsidentied
3. MAIN PARTS AND CONTROLS
