Technical specifications
4812162601_G.pdf2021-04-14
Amplitude High Low Compaction dataAmplitude High Low Compaction data
CA2500D 1,8 0,9 (mm)CA2500D 1,8 0,9 (mm)
0.07 0.035 (in)0.07 0.035 (in)
CA2500PD 2,0 1,1 (mm)CA2500PD 2,0 1,1 (mm)
0.08 0.043 (in)0.08 0.043 (in)
CA3500D 1,9 / 2,0 0,9 / 0,8 (mm) Std / HighCA3500D 1,9 / 2,0 0,9 / 0,8 (mm) Std / High
0.075 / 0.08 0.04 / 0.03 (in)0.075 / 0.08 0.04 / 0.03 (in)
CA3500PD 1,8 / 2,0 1,0 / 1,0 (mm) Std / HighCA3500PD 1,8 / 2,0 1,0 / 1,0 (mm) Std / High
0.07 / 0.08 0.04 / 0.04 (in)0.07 / 0.08 0.04 / 0.04 (in)
CA4000D 2,0 / 2,1 0,8 / 1,0 (mm) High / VM4CA4000D 2,0 / 2,1 0,8 / 1,0 (mm) High / VM4
0.079 / 0.08 0.03 / 0.04 (in)0.079 / 0.08 0.03 / 0.04 (in)
CA4000PD 2,0 1,0 (mm)CA4000PD 2,0 1,0 (mm)
0.08 0.04 (in)0.08 0.04 (in)
Vibration frequency High amplitude Low amplitude Compaction dataVibration frequency High amplitude Low amplitude Compaction data
CA2500D 33 34 (Hz)CA2500D 33 34 (Hz)
1 980 2 040 (vpm)1 980 2 040 (vpm)
CA3500D 31 / 30 34 / 30 (Hz) Std / HighCA3500D 31 / 30 34 / 30 (Hz) Std / High
1 860 / 1 800 2 040 / 1 800 (vpm)1 860 / 1 800 2 040 / 1 800 (vpm)
CA2500PD, CA3500PD 30 30 (Hz)CA2500PD, CA3500PD 30 30 (Hz)
1 800 1 800 (rpm)1 800 1 800 (rpm)
CA4000D/PD 30 30 (Hz)CA4000D/PD 30 30 (Hz)
1 800 1 800 (rpm)1 800 1 800 (rpm)
Centrifugal force High amplitude Low amplitude Compaction data Centrifugal force High amplitude Low amplitude Compaction data
CA2500D 250 130 (kN)CA2500D 250 130 (kN)
56 250 29 250 (lb)56 250 29 250 (lb)
CA2500PD 260 150 (kN)CA2500PD 260 150 (kN)
58 500 33 750 (lb)58 500 33 750 (lb)
CA3500D 280 / 270 170 / 120 (kN) Std / HighCA3500D 280 / 270 170 / 120 (kN) Std / High
63 000 / 60 750 38 250 / 27 000 (lb)63 000 / 60 750 38 250 / 27 000 (lb)
CA3500PD 260 / 280 150 (kN) Std / HighCA3500PD 260 / 280 150 (kN) Std / High
58 500 / 63 000 33 750 (lb)58 500 / 63 000 33 750 (lb)
CA4000D 270 / 280 120 / 150 (kN) High / VM4CA4000D 270 / 280 120 / 150 (kN) High / VM4
60 750 / 63 000 27 000 / 33 750 (lb)60 750 / 63 000 27 000 / 33 750 (lb)
CA4000PD 280 150 (kN)CA4000PD 280 150 (kN)
63 000 33 750 (lb)63 000 33 750 (lb)
