Fazzini F-18 - Page 10

Suction Pump
F-18/F-36/F-20/F-40
Service Manual
Doc : Service Manual - F-18-36-20-40 Rev. 1 del 20 SEP 2005
Page 10 di 12
Functional layout
4
2
3
1
Feeding wire (Brown)
Feeding wire (Blue)
Feeding wire (Brown)
Feeding wire (Blue)
43
1
IEC Power inlets
2
M
IEC double pole switch
Feeding 50/60 Hz
