Fazzini F-18 - ; WARNINGS; CAUTIONS; TECHNICAL DATA

Suction Pump
F-18/F-36/F-20/F-40
Service Manual
Doc : Service Manual - F-18-36-20-40 Rev. 1 del 20 SEP 2005
Page 3 di 12
WARNINGS
BEFORE USING THE APPLIANCE READ THE HANDBOOK
WARNINGS
THE APPLIANCE MUST BE USED BY QUALIFIED PERSONNEL
WARNINGS
DO NOT OPEN THIS DEVICE FOR ANY REASON
PLEASE CONTACT THE FAZZINI S.R.L. TECHNICAL DIVISION FOR ANY PROBLEM SHOULD ARISE
CAUTIONS
CAREFULLY FOLLOW THE GUIDELINES WHEN USING THE APPLIANCE:
DO NOT HANDLE THE APPLIANCE WITH WET OR MOIST HANDS
DO NOT HANDLE THE PLUG WITH WET OR MOIST HANDS
DO NOT USE THE APPLIANCE UNDER THE SHOWER OR IN THE BATHTUB.
DO NOT DIP THE APPLIANCE UNDER WATER
DO NOT USE THE APPLIANCE IN THE PRESENCE OF INFLAMMABLE AND/OR EXPLOSIVE LIQUIDS, GASES OR MIXTURES
DO NOT LEAVE THE APPLIANCE EXPOSED TO ATMOSPHERIC AGENTS OR HEAT SOURCES
DO NOT LET CHILDREN OR INCAPABLE PERSONS USE THE APPLIANCE WITHOUT THE NECESSARY SUPERVISION.
BEFORE STARTING TO CLEAN THE DEVICE, MAKE SURE IT IS NOT CONNECTED TO THE ELECTRIC POWER SUPPLY
NETWORK
DO NOT USE THE APPLIANCE FOR AIMS OTHER THAN THOSE FORESEEN BY THE MANUFACTURER. USING THE
APPLIANCE UNDER DIFFERENT CONDITIONS THAN THOSE SPECIFIED IN THIS HANDBOOK MAY PREJUDICE ITS SAFETY
AND ITS TECHNICAL PARAMETERS
TECHNICAL DATA
MODEL
LENGTH
WIDTH
HEIGHT
WEIGHT
POWER SUPPLY
MAX ASPIRATION
FLOW
-WITH FILTER
-DIRECT
MEASUREMENT ON
ASPIRATION VENT
FUSE
F-18.XX
260 MM.
180 MM.
220 MM.
3,4 KG
230V- 50/60Hz
- 0,75 BAR
11 L/MIN.
18 LT/MIN
1 X 1,6A 250V
F-36.XX
260 MM.
180 MM.
220 MM.
3,9 KG
230V- 50/60Hz
- 0,75 BAR
16 L/MIN.
36 LT/MIN
1 X 1,6A 250V
F-20.XX
350 MM.
210 MM.
250 MM.
4.0 KG
230V- 50/60Hz
- 0,75 BAR
11 L/MIN.
18 LT/MIN
1 X 1,6A 250V
F-40.XX
350 MM.
210 MM.
250 MM.
4.5 KG
230V- 50/60Hz
- 0,75 BAR
16 L/MIN.
36 LT/MIN
1 X 1,6A 250V
