Fazzini F-18 - Page 6

Suction Pump
F-18/F-36/F-20/F-40
Service Manual
Doc : Service Manual - F-18-36-20-40 Rev. 1 del 20 SEP 2005
Page 6 di 12
Legenda F-18 / F-36
1 Filter
2 Vacuum drive
3 Jar drive to the filter
4 Silicone tube to the patient
5 Jar drive to the patient
6 Suction catheter CH 14
7 Main switch
8 Vacuum regulator
9 Vacuum gauge
