W4 W8
× 4
M8 × 60 mm
× 2
K
× 1
M8 × 80 mm
× 1
H
W3
× 14
M8 × 40 mm
P1
× 2
φ111 × 450 mm
P2
× 4
φ111 × 300 mm
P3
× 1
φ111 × 165 mm
P4
× 4
φ52 × 270 mm
Supporting posts
Hardware
L
× 5
I
× 9
