FEASA LED ANALYSER

FUNCTIONAL VERSION

Daisy Chain Mode

Example

Busfree 'free the bus

busc3 'All Analysers capture using range 3 High

busceF304 'poll the analyser F304

busgetF304 'Connect to the Analyser F304

getserial 'Confirm s/n of the Analyser

F304

gethsi01 'Get the Data for Fiber 1

000.51 100 36491

gethsi02

gethsi20

120.51 100 66542 'Data for Fiber 20

busfree

busceF461

busgetF461 'Connect to the next Analyser F461

getserial 'Confirm to Analyser

F461

gethsi01 'Get the Data for Fiber 1

000.51 100 36491

gethsi02

gethsi20 'Get the Data for Fiber 20

Repeat this sequence for all Analysers in the chain.
