FEASA LED ANALYSER
FUNCTIONAL VERSION
The RGB and Hue values in Figure 2 show how different Colour LEDs can be identified.
LED R G B HUE SATURATION
Red 253 1 1 0 100%
Green 24 208 23 120 89%
Blue 2 13 240 238 99%
Yellow 76 171 8 95 96%
Orange 224 28 2 7 99%
White 71 72 112 See Page 13 21%
Figure 2.
The RGB or Hue values are used to identify different Colour LEDs.
Every LED tested by the LED Analyser will have a set of RGB values generated for analysis.
These values are converted automatically to Hue and Saturation (whiteness) and can be read
out through the Serial or ICT ports.
Back to Index
9
