FSC-DB200 User Guide
Shenzhen Feasycom Technology Co.,Ltd www.feasycom.com
1. Introduction
Overview
The FSC-DB200 development board integrates Type-C
(including UART/USB/charging/power supply), audio
input and output, microphone, lithium battery, buttons,
reset buttons, 2.54mm pitch headers, status indicators,
etc.
It can be used in conjunction with our serial port
assistant and AT commands for functional testing, which
is convenient for customers to familiarize themselves
with our products, shorten the development cycle, and
improve efficiency.
Features
All-in-one Type-C
Universal 3.5 headphone jack input
Universal 3.5 headphone jack output
Built-in microphone, convenient for call test
Lithium battery/USB powered
Key control (switch on/off/pause playback/volume
size/up and down music) and one-key reset
2.54mm spacing row of pins to facilitate DuPont wire
connection
Multi-function indicator light indicates status
RF interface (non-standard), convenient to test RF
signal
Built-in USB to serial port chip
Built-in headphone amplifier chip, which can drive
16/32 ohm headphone
Reserved connection holes for Arduino board
Application
BT1026X
BT1006X
BT806X
BT958
Picture as below showing：
Figure 1: FSC-DB200 Picture
