MicroPulse MPSxxU Manual
9
MPSxxU Light Head
Federal Signal www.fedsig.com
Quick Reference
Table 4 Light Head Wiring
Wire Internal Flasher Mode External Flasher Mode
Red To +VDC for Mode 1 To +VDC for Color 1 Steady
White To +VDC for Mode 2 To +VDC for Color 2 Steady
Brown To +VDC for Mode 3 To +VDC for Color 3 Steady
Green FSLink Sync To - Chassis Ground
+VDC for
Programming
Black To - Chassis Ground To - Chassis Ground
Table 5 Programming Quick Reference
Program Wire Held Feedback Programming Sel.
Less than 1 Second 1 Flash Pattern Select
Between 1-2 Seconds 2 Flashes FSLink Sync or Alt
Between 2-3 Seconds 3 Flashes Flash Color(s) Select
Between 3-4 Seconds 4 Flashes Color Order Select
Between 4-5 Seconds 5 Flashes Split Flash Select
Between 5-6 Seconds 6 Flashes Brightness Select
Between 6-7 Seconds 7 Flashes Default ALL Modes
Table 6 Internal Flasher Mode Defaults
Mode 1 - Flash Pattern #10 Steady Burn, Cruise Intensity
Mode 2 - Flash Pattern #1 Triple 92.3 FPM, All Colors
Mode 3 - Flash Pattern #10 Steady Burn, Full Intensity
Table 7 Flash Patterns
No. Description Flash Pattern Compliance
1 Triple 92.3 SAE/NFPA/TRIPLE-K
2 Triple 90 SAE/NFPA/TRIPLE-K
3 Single 122 SAE/R65/NFPA/TRIPLE-K
4 Single 75 SAE/TITLE13/NFPA/TRIPLE-K
5 Single 90 SAE/TITLE13/NFPA/TRIPLE-K
6 Single 113 SAE/TITLE13/NFPA/TRIPLE-K
7 Cruise Flicker n/a
8 Mega 375 -
9 Random SAE/TITLE13
10 Steady Burn n/a
11 Single 75 SAE/TITLE13/NFPA/TRIPLE-K
12 Single 120 SAE/TITLE13/NFPA/TRIPLE-K
13 Double 80 SAE/TITLE13/NFPA/TRIPLE-K
14 Double 120 SAE/TITLE13/R65/NFPA/
TRIPLE-K
15 Triple 80 SAE/TITLE13/NFPA/TRIPLE-K
16 Triple 120 SAE/TITLE13/NFPA/TRIPLE-K
17 Quad 60 SAE/TITLE13
18 Quad 75 SAE/TITLE13/NFPA/TRIPLE-K
19 Quad 95 SAE/TITLE13/NFPA/TRIPLE-K
20 FedPulse 75 SAE/TITLE13
21 Quint 75 SAE/TITLE13/NFPA/TRIPLE-K
22 Seven X 80 SAE/TITLE13/NFPA/TRIPLE-K
23 SingleQuad 120 SAE/TITLE13/NFPA/TRIPLE-K
24 Decelerating 60 SAE/TITLE13
25 Accelerating 60 SAE/TITLE13
