4
Ejemplo instalación
Installation example
E GB
POSICIÓN SUPERIOR
UP POSITION
E
GB
SENTIDO MARCHA
VEHÍCULO
FRONT VEHICLE
E
GB
TALADRO DESAGUE
DRAIN HOLE
E
GB
SOPORTE VEHÍCULO
VEHICLE SUPPORT
E
GB
Nitrato de zinc
Zinc nitrate
GB
E
Ø 8 mm
IMPRESCINDIBLE
ESSENTIAL
E
GB
UTILIZAR TORNILLERIA ORIGINAL
USE ORIGINAL BOLT KIT
E
GB
SCS1000-D / ALS1000-D
NO
SUELO / GROUND
NO instalar
hacia el SUELO
NOT install to
the GROUND
SUELO / GROUND
ADVERTENCIA MUY IMPORTANTE
Instalar el sifón del cable en dirección al SUELO.
VERY IMPORTANT WARNING
Install U-bend cable toward the GROUND.
SUELO / GROUND
SIFÓN CABLE
CABLE U-BEND
E
GB
