2. Assembly
Unpacking
Remove lawn mower from carton and check thoroughly for additional loose parts.
Handle Setup And Height Adjustment
Open out the handle and screw the handles parts with the two Nuts and Bolts by tool,
And screw the handles parts with the four knobs and Bolts by hand.
Put the recoil starter on the right of the handle and fix the cable with the plastic collar.
Introduce the rope of the recoil starter handle on its support guide rope.
If you want to adjust height of the handle bar, you can choose” L” or “H” two holes in
left-right Bracket to fix the handle bar with screws and knobs.
The “H” hole is high position of the handle bar, and the “L” hole is low position of the
handle bar.
