4.1 Performance Features of the People Counter ID ISC.ANT.GPC
The product ID ISC.ANT.GPC, short form “Gate People Counter” or “GPC”, are made for mount-
ing in the gate antennas ID ISC.ANT1520/680.
A Gate People Counter consist of a People Counter board (PC) and one Radar Detector! The
product ID ISC.ANT.GPC-E2 Extension Radar Detector is used to extend the People Counter to a
second gate aisles.
The People Counter has two counters per aisle. The values of the incoming and outgoing persons
will be separately captured.
Fig. 1: Gate People Counter Structure (2-3 antennas, 1-2 gate aisles)
A change of the counter values will be stored in the EEPROM of the People Counter board. By
sending the command “0x78 Set People Counter” the values could be set/reset to the needed
value.
The counter values will be sent every 5 seconds to the LCD Display.
People
Counter 1
Radar
Detector 1
Out / LED 1
ID ISC.ANT.GPC
-
E
2
Extension Radar Detector
(e.g. 2’cd aisle of the gate)
Radar
Detector 2
Gate antenna
ID ISC.ANT1520/680.GPC
Reader
LCD Display

Feig Electronic ID ISC.ANT1520/680 Specifications

General

Frequency Range	865-928 MHz
Antenna Gain	6 dBi
Polarization	Linear
IP Protection Class	IP65
Material	Aluminum
Connector Type	N-Type female
