Fein MM 300 Plus - Positioning the tool (figure 3).; Tool positioning steps; Ejecting the application tool (figure 4).; Tool ejection procedure

12
en
Positioning the tool (figure 3).
The application tool can be offset in 30° steps
and fastened in the most favorable working
position.
Ejecting the application tool (figure 4).
To eject the application tool and have the
starting position set, move the clamping lever
back to the stop; in this, the application tool
is also released.
Pay attention that the application tool is
seated straightly the tool holder.
For all work or when changing application
tools, always wear protective gloves.
Danger of injury from the sharp edges of the
application tools. Application tools can
become very hot while working. Danger of
burns!
3.
0°
30°
60°
90°
90°
60°
30°
180 °
4.
2.
1.
Fig. 3
180 °
4.
2.
3.1.
4.
Fig. 4
