FeinTech VSP01401 - INSTALLATION AND OPERATION; INSTALLATION AND MAINTENANCE

7
Input source Display supports HDCP 2.2 Display doesn‘t support HDCP 2.2
HDCP 2.2 4k@60Hz HDCP 2.2 4k@60Hz HDCP 1.4 1080p@60Hz
HDCP 2.2 4k@24Hz HDCP 2.2 4k@24Hz HDCP 1.4 1080p@60Hz
HDCP 1.4 4k@24Hz HDCP 2.2 4k@24Hz HDCP 1.4 4k@24Hz
INSTALLATION AND OPERATION
1. Connect the HDMI signal source (e.g., Bluray player) to the HDMI input.
2. Connect the HDMI displays (e.g. TV and projector) to the HDMI outputs.
3. Connect the power supply to the HDMI splitter and plug it into an electrical outlet. The LEDs of the splitter light up
as soon as a signal is present and the output device is switched on.
CONNECTION SCHEME
Caution: Be careful when inserting and unplugging the HDMI cables to prevent the plug contacts
from getting dirty or damaged. Disconnect the power supply from the mains and turn it on only after
connecting. Please also pay attention to a good quality of HDMI cables.
INSTALLATION AND MAINTENANCE
• Please do not cover the housing or build in the unit to avoid overheating.
• Keep away from heat sources, water and moisture.
• Do not place heavy objects on the device or the connection cables.
• Do not open or drill holes in the housing.
• Use only the supplied power supply or ensure identical performance data when replacing.
• Clean only with a soft, dry cloth. Please do not use a sharp detergent or similar.
