3 / 10
LISTA DE PARTES/PART LIST
No. Descripción/Description pzs FE-131 pzs FE-132 pzs FE-133 pzs FE-134
1 Gabinete Exterior/ Exterior Cabinet 1 71-3101 1 71-3201 1 71-3301 1 71-3401
2 Cajon Interior / Interior Cabinet 1 71-3102 1 71-3202 1 71-3302 1 71-3402
3 Puerta / Door 1 71-3103 1 71-3203 1 71-3303 1 71-3403
6 Tapa Posterior / Back Cover 1 71-3106 1 71-3206 1 71-3306 1 71-3406
8 Soporte Resitencia/ Heater Support 1 71-3108 1 71-3208 1 71-3208 3 71-3108
10 Elemento Calefactor/ Heating Element 1 71-3110 2 71-3110 2 71-3110 3 71-3110
11 Tapa Resistencia/ Heating Cover 1 71-3111 1 71-3211 1 71-3311 2 71-3411
12 Entrepano / Shelves 2 71-3112 2 71-3212 2 71-3312 2 71-3412
13 Sensor Temperatura/ Sensor 1 71-3113 1 71-3113 1 71-3113 1 71-3413
15 Empaque Puerta / Door Gasket 1 71-3115 1 71-3215 1 71-3315 1 71-3415
16 Jaladera / Handle 1 71-3116 1 71-3116 1 71-3116 1 71-3116
18 Panel de Control / Control Panel 1 71-3118 1 71-3118 1 71-3118 1 71-3118
19 Aislador Largo / Insulator 2 71-3319 3 71-3319 3 71-3319 12 71-3219
20 Cable Alimentacion / Plug Cable 1 51-7032 1 51-7032 1 51-7032 1 51-7032
24 Cremallera / Rack 4 71-3124 4 71-3224 4 71-3324 4 71-3424
25 Soporte Superior Puerta/ Door Support 1 71-3125 1 71-3125 1 71-3125 2 71-3125
26 Soporte Inf. Puerta/Door Support 1 71-3126 1 71-3126 1 71-3126 2 71-3426
27 Puerta Interior / Inner Door 1 71-3127 1 71-3227 1 71-3327 2 71-3427
28 Regulador / Air Regulator 1 71-3128 1 71-3128 1 71-3128 1 71-3128
29 Protector Cable / Cable Gasket 1 31-3025 1 31-3025 1 31-3025 1 31-3025
31 Switch-Piloto/ Pilot Switch 1 71-3132 1 71-3132 1 71-3132 1 71-3132
32 Led de Ciclo / Cycle led 1 20-0144 1 20-0144 1 20-0144 1 20-0144
33 Perilla Control / Control Knob 1 71-3133 1 71-3133 1 71-3133 1 71-3133
34 Aislante Lateral / Side Insulator 2 71-3151 2 71-3234 2 71-3334 2 71-3434
35 Aislante Posterior/ Back Insulator 1 71-3150 1 71-3235 1 71-3335 1 71-3435
36 Aislante Superior/ Upper Insulator 2 71-3152 2 71-3236 2 71-3336 2 71-3436
37 Cable Conector Bajante/ Cable 2 71-3177 2 71-3237 2 71-3237 6 71-3437
38 Cable Conector Bajante / Connector 1 71-3238 1 71-3238
39 Cable Conector / Connector 1 71-3239 1 71-3239 2 71-3439
41 Porta Sensor / Sensor Holder 1 71-3171 1 71-3171 1 71-3171 1 71-3171
42 Interruptor Puerta / Door Switch 1 20-0361 1 20-0361 1 20-0361 1 20-0361
43 Patas de Hule / Rubber Bolt 4 41-0929 4 41-0929 4 41-0929 4 41-0929
44 Aislador Boton / Insulator 4 31-3047 8 31-3047 8 31-3047 12 31-3047
45 Empaque Puerta Interior/ Inner Door Gasket 1 71-3174 1 71-3244 1 71-3344 1 71-3444
46 Control Temperatura/ Temp. Control 1 71-3134 1 71-3134 1 71-3134 1 71-3134
47 Arnes Conexiones / Connecting Arnes 1 71-3147 1 71-3247 1 71-3247 1 71-3447
54 Cubierta Foco / Light Cover 1 71-3154 1 71-3154 1 71-3154 1 71-3154
56 Foco / Light 1 71-3156 1 71-3156 1 71-3156 1 71-3156
70 Pija Inox. A.R. 8 x 1/2 / Self Screw 12 02-03-3146 15 02-03-3146 15 02-03-3146 16 02-03-3146
72 Pija A.R. 8 x 1/2 / Metal Selfscrew 18 02-03-3125 22 02-03-3125 24 02-03-3125 46 02-03-3125
74 Tornillo cromado 10-32 x 1/2 / 10-32 x 1/2 Screw 2 02-00-0609 2 02-00-0609 2 02-00-0609 4 02-00-0609
79 Tornillo 8-32 x 1/2 / 8-32 x 1/2 Screw 13 02-71-0039 17 02-71-0039 17 02-71-0039 26 02-71-0039
pzs 131AD pzs 132AD pzs 133AD pzs 134AD
2 Cajon Interior/ Interior Cabinet 1 71-3502 1 71-3602 1 71-3702 1 71-3802
7 Base Resistencias/ Heating Base 1 71-3107 1 71-3207 1 71-3307 1 71-3407
13 Sensor Temperatura/ Sensor 1 71-3114 1 71-3114 1 71-3114 1 71-3414
17 Panel de Control / Control Panel 1 71-3117 1 71-3117 1 71-3117 1 71-3417
46 Control de Temperatura / Temperature control 1 71-3143 1 71-3143 1 71-3143 1 71-3143
47 Arnes Conexiones / Conecting Arnes 1 71-3148 1 71-3148 1 71-3148 1 71-3148
51 Display / Display 1 71-3135 1 71-3135 1 71-3135 1 71-3135
52 Alarma Auditiva / Buzzer 1 71-1534 1 71-1534 1 71-1534 1 71-1534
53 Interruptor con Llave/ Key Switch 1 20-0607 1 20-0607 1 20-0607 1 20-0607
57 Base Motor / Motor Base 1 71-3145 1 71-3145 1 71-3145 1 71-3145
58 Turbina / Blower 1 71-3146 1 71-3246 1 71-3246 1 71-3446
59 Motor / Motor 1 71-3144 1 71-3144 1 71-3144 1 71-3144
