41
DIAGRAM 1 - Parts List (7/01)
DIAG
LOC.
PART
NO.
QTY
REQ
DESCRIPTION
DIAG
LOC.
PART
NO.
QTY
REQ
DESCRIPTION
1 169573 1
Cart Assy (Incl. Items 2-4)
- - 189248 1
Pivot Head Assy, Complete (Incl. 33-73)
2 169576 1 Conveyor Cart w/ V-Top (only) - - 189251 1
Pivot Head Assy, Basic (Incl. 45 - 55)
45 169766 1 Motor Base, Pivot (only)
- - 030049 1
Cart Wheels, Set/4 (Incl. items 3-4)
46 169773 2 Bushing, Pivot
3 030822 4 Cart Wheel (only)
4 032366 4 Nut, KEPS, 5/16”-18 47 052004 1
Blade Shaft Assembly (Incl. Items 48–53)
48 052006 1 Blade Shaft
5 051000 1 Rip Guide 49 071081 2 Bearing
6 189737 1 Knob, 1/4”-20 x 1” 50 071110 1 Spring Washer
51 169522 1 Inner Collar
7 171038 1
Pan Assembly (Incl. Items 8–18)
52 169523 1 Outer Collar
8 171011 1 Pan (only) 53 020176 1 Nut, Hex Jam Thin, 5/8” – 18
9 169591 2 Rail – R/L
10 020370 4 Capscrew, Hex Hd., ¼” – 20 x 3/4" 54 020060 1 Key, 3/16” Sq. x 1”
11 020195 4 Locknut, Fiber, ¼” – 20
12 171017 1 Frame, Pan 55 68822 1 Pulley, Arbor: 6GJ1.75-.627 w/SS,
13 030386 1 Drain Plug
14 189024 1 Decal: Tile Master (Pan) 56 58964 1 V-Belt: Poly 280J6
15 171015 2 Clamp
16 051065 8 Plastic Tab 57 172101 1 Pulley, Motor: 6GJ2.8 w/SS,
17 020301 2 Capscrew, Hex Hd., ¼” - 20 x 5/8”
18 020784 2 Lockwasher, Split, ¼” 58 020060 1 Key, 3/16” Sq. x 1”
19 050218 1
Water Pump Assy (Incl. Items 20-21)
59 169422 1 Motor: 1.5HP-HT, 1725 RPM, 115V/60/1
20 197237 1 Hose Barb ¼” FPT x ¼” OD A 001501 1 Motor Switch (169422)
21 161134 1 Valve, Flow Control B 169492 1 Manual Reset Overload (169422)
- - 169493 1 Capacitor, Start (169422)
22 169563 1
Water Tube Assy: ¼” Y x 32”
- - 169494 1 Capacitor, Run (169422)
23 189022 1 Chassis
24 171037 7 End Caps 60 178825 4 Flange Bolt, 5/16” - 18 x 1”
25 043260 2 Set Collar 1” Dia. 61 020197 4 Locknut, Fiber, 5/16” – 18
26 189015 1 Lock Bar, D/Limiting
27 020318 1 Capscrew, Hex Hd., 5/16” - 18 x 2-1/4” 62 169582 1
Blade Guard Assy (Incl. 63-73)
28 020742 1 Washer, Flat, 5/16” 63 169548 1 Blade Guard (only)
29 020197 1 Locknut, Fiber, 5/16” – 18 64 169365 1 Splash Guard
30 169486 1 Knob, 5/16” – 18 x 1” 65 169366 1 Screw, Self-Tapping #8 x 3/8”
31 020742 2 Washer, Flat 5/16” 66 020739 1 Washer, Flat #10
32 161641 1 Wrench 67 163248 1 Rubber Sponge Strip
68 020126 1 Carriage Bolt, 5/16” -18 x 2-1/2”
33 169679 1
Belt Guard Assy (Incl. Items 34-42)
69 020763 1 Washer, Flat 5/16”
34 171013 1 Belt Guard (only) 70 020245 1 Locknut, Wing 5/16” – 18
35 020762 2 Washer, Flat ¼” SAE 71 189026 1 Decal: Felker (Blade Guard – Inner)
36 021423 2 Capscrew, Hex Hd., ¼” - 20 x ½” 72 189025 1 Decal: Felker (Blade Guard – Outer)
37 178825 1 Flange Bolt, 5/16” - 18 x 1” 73 169586 1 Decal: TILE MASTER (Outer)
38 020197 1 Locknut, Fiber, 5/16” – 18
39 171026 1 Decal: Large Belt Guard 74
40 189027 1 Decal: Small Belt Guard 75 - - - - - 1 Blade: 10” (254mm) - FELKER
41 187043 1 Decal: Warning
42 169499 1 Belt Guard Bracket
43 178826 2 Flange Bolt, ¼” – 20 x ¾”
44 020195 2 Locknut, Fiber, ¼” – 20
To Next Page
