External Antenna
Self-locking Nut
xFOB Connection Indicator
Pairing, Override
and Stop Button
Light and Sound Alarm
Internal Antenna
XFOBXHUB
xHUB will indicate low battery on the xFOB by blinking
the light bar respective to the connected xFOB.
xFOB Battery
Measurements and performance
Weight 164g / 5.8oz.
Housing material ASA / TPU / PBT / POM – RoHS
Temperature range From -15°C / 5°F to 55°C / 131°F
Voltage Source 10-32Vdc
Energy consumption
Active mode
2.5W max. at 13.8Vdc, Standby: <30mA, <0.4W max.
at 13.8V
Fuse 1A-3A
Alarm decibel level >85db
Kill Switch max electricity 8A continuously, 10A puls
Wireless performance
Frequency area EU: 868 MHz US: 915 MHz
RF signal (in) 10 dBm max.
RF signal (out) 10 dBm max.
4D Antenna diversity
Measurements and performance
Weight 10g / 0.35oz.
Housing material ASA / TPU / POM
Temperature range From -15°C / 5°F to 55°C / 131°F
Voltage Source Coin Cell Battery - 3V nominal
Power consumption 0.3 µA in sleep (0.00033 W) 30 mA in active mode (0.098W)
Battery life 300 hours continous usage
Wireless performance
Frequency area EU: 868 MHz US: 915 MHz
RF signal (in) 10 dBm max.
RF signal (out) 10 dBm max.
4D Antenna diversity
Battery xFOB
Battery type CR2032
Battery voltage 3V lithium battery
The MOB+ is tested and certified to meet all the
current standards – for your safety. ABYC A33 &
E-11 Compliant (US Emergency engine/propulsion
kill devices standard)
CERTIFICATIONS
Wireless US: FCC Part 15C
EU: R&TTE - ETSI EN 300 220
EMC US: CISPR16
EU: EN 301 489
IP Grade xFOB™: IP68, xHUB™: IP67 EN60945
Materials RoHS (2002/95/EC)
Flammability IEC 60950 1&22
Web: fellmarine.com/support
Email: support@fellmarine.com
Phone US: +1 855-683-FELL
Phone EU: +47 32 82 82 80
We are here to help
Please feel free to contact us with
any inquiry.
