COMB DIAMETER & DOCUMENT SIZES
3
SET UP
765
21 3
4
1. Ensure the machine is on a
stable surface.
2. Check waste tray is empty
and correctly fitted.
3. The machine is supplied with
loose power leads. Select the
correct lead for the appropriate
power supply.
4. Fit the lead to the machine
(the socket is at the rear of the
machine).
5. Plug the machine into an easily
accessible mains socket. Switch the
mains supply on.
6. Switch the machine on (located
at the rear of the machine)
7. Lift the lid. Check the green power
neon is on. Ensure the comb-opening
lever is pushed backwards.
mm inch number of pages
6mm 1/4” 2-20
8mm 5/16” 21-40
10mm 3/8” 41-55
12mm 1/2” 56-90
16mm 5/8” 91-120
18mm 1 1/16” 121-150
22mm 7/8” 151-180
25mm 1” 181-200
32mm 1 1/4” 201-240
38mm 1 1/2” 241-340
