Vehicle Introduction
MAIN ELECTRICAL COMPONENTS
1 POWER BATTERY CHARGING PORT
2 USB CHARGING PORT
3 POWER OFF SWITCH
4 OBD
5 MCU
6 MOTOR
7 POWER BATTERY BOX
8 HORN
9 DC-DC CONVERTER
F VCU
G 12 V BATTERY
H ABS CONTROLLER
Caution
If the electrical system fails, please take your
motorcycle to a qualified repair store as soon
as possible for an overall inspection and repair.
