Fender Frontman 15B Service Manual

FRONTMAN 15B
PARTS LIST
NOTE: SHADED ITEMS ARE FOR REFERENCE ONLY
PRINTED CIRCUIT BOARD ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
047499 PCB ASSY BXR 15/ FRONTMAN 15B
9 026517 CAP AE AX 2.2µF 50V C2,4,5,13,18,20,21,22,23
1 038693 CAP AE AX 47µF 16V C15
2 028471 CAP AE RDL 47µF 50V 20% C26,27
2 033607 CAP AE RDL 2200µF 35V 20% C24,25
1 038703 CAP CA .1µF 50V C12
1 038873 CAP CA 22PF 100V C14
1 038699 CAP CA 100PF 100V C3
1 039259 CAP CA 220PF 100V C1
1 039260 CAP CA 270PF 100V C10
1 038700 CAP CA 390PF 50V C6
1 039267 CAP CA 3900PF 100V C32
1 038702 CAP CA 6800PF 50V C7
1 027286 CAP MPF .47µF 63V C8
1 033588 CAP PFF RDL .01µF 100V 10% C16
1 033591 CAP PFF RDL .033µF 100V 10% C19
4 033592 CAP PFF RDL .047µF 100V 10% C28,29,30,31
1 038656 CONTROL 10KB SNAP IN R7
3 038655 CONTROL 50KB W/CD SNAP IN R8,9,10
6 064089 DIODE 1N4003 CR3,4,15,16,17,18
9 006260 DIODE 1N4448/1N914B SIGNAL CR1,2,5,6,8,9,10,11,12
2 047140 DIODE ZEN 1N5349B 12V 5W CR13,14
2 025996 FUSE CLIP PCB .250 & 5MM FUSE XF1
1 068411 FUSE QA 1-1/4X1/4 250V 0.5A F1 (100/120V ONLY)
1 020781 FUSE QA 20mm x 5mm 250V .25A F1 (230V EXPORT ONLY)
1 041952 HEATSINK BRONCO
1 027404 IC CA3080AE OTA U4
3 016795 IC DUAL OP AMP TL072 U1,2,5
1 029912 IC POWER AMP PC1188H 20W U3
1 041988 INSULATOR MICA 10 PIN SIP AT HEATSINK
2 037036 JACK PHONE PCB MONO CA PREMIUM J1,3
1 031570 JACK PHONE PCB STEREO PREMIUM J2
9 020888 JUMPER WIRE 22GA. .5X.175 W1,2,3,4,5,6,7,8,9
1 028039 LED RED 5X5MM SLB-55VR3 LD1
1 047499 PCB ASSY BXR 15 (STUFFED)
1 047498 PCB FAB BXR 15 (RAW BOARD)
1 024952
RES CF 1/4W 5% 100Ω
R31
2 024959
RES CF 1/4W 5% 330Ω
R5,45
2 024965 RES CF 1/4W 5% 1K R19,48
2 024971 RES CF 1/4W 5% 2.2K R11,14
2 024972 RES CF 1/4W 5% 2.7K R6,34
1 024975 RES CF 1/4W 5% 3.9K R41
FRONTMAN 15B
PARTS LIST
PRINTED CIRCUIT BOARD ASSEMBLY
CONTINUED
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 024977 RES CF 1/4W 5% 4.7K R36
1 028948 RES CF 1/4W 5% 6.2K R32
1 024980 RES CF 1/4W 5% 8.2K R23
5 024981 RES CF 1/4W 5% 10K R15,25,26,28,30
5 024989 RES CF 1/4W 5% 33K R1,4,24,27,29
2 024993 RES CF 1/4W 5% 47K R18,21
4 028990 RES CF 1/4W 5% 51K R37,38,39,40
1 024996 RES CF 1/4W 5% 82K R12
1 024997 RES CF 1/4W 5% 100K R20
1 024998 RES CF 1/4W 5% 120K R33
1 024999 RES CF 1/4W 5% 150K R13
2 025059 RES CF 1/4W 5% 220K R3,17
1 025061 RES CF 1/4W 5% 330K R16
1 025069 RES CF 1/4W 5% 1M R2
1 029083
RES CF 1/2W 5% 10Ω
R22
1 026549 RES CF 1/2W 5% 1.5K R42
4 028045
RES FILM 1W 5% 220Ω
R43,44,46,47
2 027638 SCRW TF 4-40X3/8 HWHS ZI .1HD AT HEATSINK
2 032908 SCRW TF 6-32X3/8 PHP ZI AT HEATSINK
1 9904701440 SPACER LED .7X.125 BLUE AT LD1
1 014408 XSTR PNP MPSA63 TO-92 Q1
CHASSIS ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
051212 CHASSIS ASSY FRNTMAN 15B
4 033206 BUSHING KNOB SPACER (@ CONTROLS)
1 007565 BUSHING SR.625X.125X37/64 BLK (@ POWER CABLE)
1 026527 CABLE ASSY PWR 120V.187 TABS
1 022491 CLAMP CABLE NYL SCRW MNT 5/16
4 026402 KNOB POINTER BLACK
1 047502 PANEL FRONT BXR 15
1 048440 PLATE REAR BXR 15
1 038900 SCRW TF 6-32X1/4 PHP ZI (@ GROUND LUG)
2 037353 SCRW TF 6-32X3/4 PHP ZI (PCB MOUNT)
1 051100 PANEL FRONT FRONTMAN 15B
1 051330 CABLE ASSY 120V 6 FT
3

Fender Frontman 15B Specifications

Power

power requirement (100V version)	100V AC, 50/60 Hz, 45W
power requirement (120V version)	120V AC, 60 Hz, 45W
power requirement (230V version)	230V AC, 50 Hz, 45W
power requirement (240V version)	230V AC, 50 Hz, 45W
power output	15W R.M.S.

Speaker and Impedance

rated load impedance	8Ω
speaker complement	One 8Ω Special Design, 8" Speaker (P/N 025421)
input impedance	202k Ω

Dimensions and Weight

height	15 in. 38.1 cm
width	17.25 in. 34.3 cm
depth	9.75 in. 24.8 cm
weight	21 lbs. 9.5 kg
