A PRODUCT OF:
FENDER MUSICAL INSTRUMENTS CORP.,
CORONA, CA 91720
Part Number: 120V Version: 022-8500-000
Aust. Version: 022-8530-000
UK Version: 022-8540-000
230V Version: 022-8560-000
100V Version: 022-8570-000
Type Specification: PR 299
Power Requirements: 100V Version: 100VAC, 50/60Hz, 180W
120V Version: 120VAC, 60Hz, 180W
230V Version: 230VAC, 50Hz, 180W
240V Version: 240VAC, 50Hz, 180W
POWER AMPLIFIER SECTION:
Power output: 50W R.M.S.
Rated load impedance: 8Ω
Distortion at 50 watts: Less than .1% @ 1 kHz, before compression.
Less than 1% @ 1 kHz, maximum compression.
Sensitivity: 370 mV R.M.S.
Input impedance: 33 kΩ
DELTACOMP
TM
range: 20 dB
PREAMP SECTION:
Input impedance: Phone: 36 kΩ
Sensitivity for 50 W: Phone: 28 mV
CHANNEL AND MASTER
VOLUME at maximum, all
tone controls at “0”
Equalizer: Low +/- 12 dB @ 100 Hz (shelving)
Low Mid +/- 12 dB @ 338 Hz
High Mid +/- 12 dB @ 1188 Hz
High +/- 12 dB @ 4kHz (shelving)
PHYSICAL SPECIFICATIONS:
Height: 22" (55.9 cm)
Width: 18" (45.7 cm)
Depth: 12" (30.5 cm)
Weight: 46 lbs (21 kg)
Speaker Complement: 12” Fender Special Design (P/N 047539)
Single piezo horn (P/N 049260)
WARNING: NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED PERSONNEL ONLY.
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE.
THIS EQUIPMENT CONFORMS TO
THE FOLLOWING DIRECTIVES :
EMC 89/336/EEC AND LV 73/23/EEC
KXR 60 SPECIFICATIONS
