Fender TELEPATH Wireless System - Page 4

How to use
1. Turn on the Transmitter and Receiver power, hold on the Power button 3 sec.
2. Transmitter connect to Guitar
3. Receiver connect to the guitar pedal or guitar amp
How to pair
Hold on the Power / sync button 5sec. The Status Led will flash red and blue led. After successful
pairing the Status Led will be green.
5.8Ghz Frequency Tables
1 Frequency point
5730MHZ
9 Frequency point
5789MHZ
2 Frequency point
5735MHZ
10 Frequency point
5799MHZ
3 Frequency point
5743MHZ
11 Frequency point
5804MHZ
4 Frequency point
5753MHZ
12 Frequency point
5811MHZ
5 Frequency point
5758MHZ
13 Frequency point
5820MHZ
6 Frequency point
5764MHZ
14 Frequency point
5830MHZ
7 Frequency point
5774MHZ
15 Frequency point
5836MHZ
8 Frequency point
5781MHZ
16 Frequency point
5844MHZ
Specifications
5.8Ghz bandwidth
5725 - 5850MHz
Working Range
Up to70ft actual range; depends on RF signal
absorption, reection and interference.
Audio Frequency Response
20Hz – 20KHz(-2dB)
Dynamic Range & Signal-To-Noise
Ratio
110dB
Battery Life
8 Hours
RF Sensitivity
-90dBm
Total Harmonic Distortion
<0.1%, 100mVrms 1Khz
RF Output Power
<25 mW E.I.R.P. max
Latency
Less than 5ms
High Resolution audio
24-bit/48kHz
Charging current and voltage
5V, 0.6A
