07-13
• Swing the lamp cover
k
up.
2
Replacing the uorescent lamp
in the glass cabinet (model-specic)
Procedure
• Remove the three protective caps
j
at the
top of the cornice; remove the screws and the
cornice.
• Remove the three protective caps
k
on each
side of the cabinet. Remove the screws and
pull out the entire cabinet, slanting it forward.
The uorescent lamp is now visible and can
be replaced easily.
1
2 2
Removing the integrated lamp
cover (model-specic)
for the purpose of replacing the lamps
• Push the connectors
j
on the left and right
to the side.
1
