03-8
Parking the carriage
When parking the carriage, the locking brake of
the camper must be activated.
To lock
• Pull the locking brake lever upward by the
handle
j
until it locks into place. The locking
brake lever is pressed into the nal position
by the gas pressure spring.
To release
• Press the locking brake lever back into the
original position.
Overrun coupling
We recommend that you always check
this is functioning correctly before
using the camper.
a) Hand brake
• Pull the hand brake lever and check that it
has room to move freely
• Check the condition of the pneumatic spring
• Check the condition of the spring brake
b) Support wheel and immobilizing handle
• Check wheel for damages
• Release immobilizing handle and check screw
thread
• Push support wheel up and down
• Pull immobilizing handle tight
• Use crank to crank the support wheel out and
in again
c) Tie rod bearing
• Pull out the tie rod as far as it will go
• Press the tie rod up and down - maximum
tolerance: +/- 0.3 mm (only for Euro-AE)
d) Mounting bolts for overrun coupling and
coupling
• Check that all mounting bolts for the overrun
coupling and the coupling have been pulled
tight.
3.4 Overrunning equip-
ment and wheel
brakes
