FRONT PANEL:
1. 5-Bands master Equalizer Left
channel
2. LED VU-meter master signal
3. 5-Bands master Equalizer Right
channel
4. Microphone Input Sockets
5. Microphone delay control
6. Microphone echo control
7. Microphone volume control
8. Master Volume control
9. USB Socket
10. SD socket
11. Source selector
12. MP3 play Pause button
13. MP3 Next / Volume + button
14. MP3 previous / Volume - button
Back Panel:
21. (Slave-) Speaker
output
22. Line input
23. Power switch
24. AC power cable
