TABLE OF CONTENTS
Specifications ...........................................................42
General safety instructions for machine
tools ......... 43
Extra safety instructions for
pillar drilling machines ............................................ 43
Motor specifications and electrical
requirements ............................................................. 45
Preparations .............................................................. 46
Maintenance ............................................................. 46
Lubrication ...............................................................46
Using the Laser system ............................................
46
Troubleshooting ....................................................... 47
Wiring diagram
Spare parts ................................................................
EC- Declaration of conformity ................................
SPECIFICATIONS
........................................................83
.
84
ENGLISH
Original instructions
Code no. ............................................... 23736 0102 0201 0300 0409 0508
Race ................................................................. 16 DDB 16 DDF 20 DDB 20 DDF 25 DDF
Model .............................................................. Bench Pillar Bench Pillar Pillar
Drilling capacity in steel ........................... mm 16 16 19 19 25
Spindle crown ...........................................MK 2 2 2 2 3
Spindle movement .................................... mm 80 80 80 80 120
Spindle speed ............................................ unit 12 12 12 12 12
Spindle speed .........................................r / min 210 - 2 580 210 - 2 580 120 - 2 580 120 - 2 580 150 - 2 700
Pillar diameter ........................................... mm 70 70 70 70 92
Distance spindle centre-pillar ................... mm 165 165 178 178 254
Max. distance spindle nose-table .............. mm 410 780 430 780 680
Table size .................................................. mm 260 × 260 260 × 260 290 × 290 290 × 290 475 × 425
T slot width ............................................... mm 14 14 16.5 16.5 16
Max. distance spindle nose-base plate ...... mm 600 1 240 610 1 240 1 200
Machined base plate ................................. mm 420 × 250 × 53 420 × 250 × 53 460 × 275 × 55 460 × 275 × 55 580 × 450 × 80
T slot width ............................................... mm 15 15 15 15 16
Motor voltage ................................................V 230 1 - phase 230 1 - phase 230 1 - phase 230 1 - phase 400 3 - phase
................................................................Hz 50 50 50 50 50
Motor output ..............................................kW 0.55 0.55 0.55 0.55 1.1
Height ........................................................ mm 960 1 580 980 1 630 1 710
Weight ......................................................... kg 53 60 62 70 138
.
92
