Ferax 16 DDB - Page 90

90
25 DDF Part List
No. Description Specication Qty
1 base 1
2 Hex bolt M12 × 40 4
3 Long rack 1
4 Column 1
5 Table bracket 1
6 Handle 1
7 Set screw M8 × 10 1
8 Shaft worm gear 1
9 Pin 1
10 Nut M6 1
11 Washer 20 1
12 Hex bolt M20 × 40 1
13 Table bolt 1
14 Table arm bracket 1
15 Table 1
16 Clamp bolt 1
17 Gear 1
18 Worm gear 1
19 Rack ring 1
20 Pin stop 1
21 Set screw M10 × 10 1
22 Feed shaft 1
23 Depth ring 1
24 Roll pin 1
25 Handle body 1
26 Handle 3
27 Knob 3
28 Washer 12 2
30 Screw M10 × 10 1
31 Screw M6 × 12 1
32 C - clip 1
33 Shifter bar 1
34 Slide bar bolt 2
35 Hex bolt M8 × 25 4
36 Washer 4
37 Nut M8 4
38 Nut M10 1
39 Washer 1
40 Nut M16 × 1.5 1
41 Nut M16 × 1.5 1
42 Spring cap 1
43 Torsion spring 1
44 Spring cover 1
45 Switch box 1
45 Screw M5 × 14 4
47 Switch 1
48 Screw 1
49 Clamp cord 1
50 Body 1
51 Hex bolt M8 × 16 1
52 Shifter 1
53 Slide bar 1
54 Slide bar 1
55 Motor base 1
56 Washer 2
No. Description Specication Qty
57 Nut M12 2
58 Motor 1
59 Motor pulley 1
60 Key 1
61 Setscrew M6 × 10 1
62 V - belt 1
63 Center shaft 1
64 Ball bearing 1
66 C - clip 1
67 Center pulle y 1
68 Washer 8 4
69 Screw M8 × 16 4
70 Screw M5 × 10 1
71 Washer 5 1
73 Pulley cover 1
74 V - belt 1
75 Pulley nut 1
76 Spindle pulley 1
77 Insert pulley 1
78 C - clip 1
79 Ball bearing 1
80 Spacer 1
81 Ball bearing 1
82 C - clip 1
83 C - clip 1
84 Washer 1
85 Ball bearing 1
86 Rubber washer 1
87 Spindle sleeve 1
88 Ball bearing 1
89 Spindle 1
90 Arbor 1
91 Chuck 1
94 Push - ball bearing 1
95 Micro switch assembly 1
96 Nut M6 1
97 Plate 1
98 Screw 2
99 C - clip 1
100 Power cord 1
101 Wrench 1
102 Wrench 1
103 Wedge 1
104 Washer 4
105 clamp plate 1
106 Wrench 1
107 Motor cord 1
108 Wire gasket 1
109 Hex bolt 1
117 Ship switch 1
130 Change over swtich only
for 25DF3 400 V 1
133 Push botton switch 1
152 Plate 1
153 Screw 2
