Ferm FBJ-710 - Page 3

106
Ferm Ferm 3
Spare parts list
No. Description Position
407650 Upper flange 003
407651 Lower flange 004
407652 Stopped pin + nut 005 + 006
407653 Locking knob complete 015 - 019
407655 Adjusting knob 028
407070 Spindle gear 054
407659 Handle 059
407058 pinion gear 066
406059 Rotor 071
406060 Stator 077
406061 Carbon brush set 079
406062 Carbon brush holder 080
406063 Switch 082
406064 Switch actuator 086
406065 Pull-rod for switch 090
407661 Dust bag complete 096 - 099
407662 Wrench 100
4
8
Fig. C
19
18
21
20
17
16
Fig. E
2
0
9
11
10
Fig. D
