Ferm 05
COMPRESSOR OIL-BASED +
AIR TOOL SET
The numbers in the following text correspond
with the pitcures at page 2 - 3.
Read the operating instructions carefully
before using this device. Familiarise
yourself with its functions and basic
operation. Service the device as per the
instructions to ensure that it always
functions properly. The operating
instructions and the accompanying
documentation must be kept in the
vicinity of the device.
Contents
1. Machine details
2. Safety instructions
3. Use
4. Maintenance
1. MACHINE DETAILS
Technical specifications
The value of the noise level may rise from 1 to 10
dB(A) as a function of the environment in which
the compressor will be installed.
Spray gun
Tyre inflating gun with pressure gauge
Air blow gun
Air engine cleaning gun
5M PE hose
Product information
Fig. A
1 Cover
2. Handle
3. Switch
4. Automatic stop
5. Pressure regulator
6. Quick coupler (outlet)
7. Pressure gauge (pressure regulator)
8. Pressure gauge (tank)
9. Safety valve
10.Pressure pipe
11.Air filter
12.Oil cap
13.Sump
14.Drain cock
2. SAFETY INSTRUCTIONS
Explanation of symbols
Denotes risk of personal injury, loss of
life or damage to the tool in case of
non-observance of the instructions in
this manual.
Type 5 m x 8 mm
Coupler Universal/DIN
Weight 0.25 kg
Recommended pressure 2 - 4 bar
Nozzle diameter 3.0 mm
Aluminium nozzle length 210 mm
Weight 0.55 kg
Recommended pressure 2 - 4 bar
Nozzle diameter 2.0 mm
Weight 0.15 kg
Operating pressure 0 - 8 bar
Length of hose 350 mm
Weight 0.40 kg
Operating pressure 4.5 - 6 bar
Nozzle diameter 1.5 mm
Cup capacity 500 cc
Weight 0.55 kg
Voltage 230 V~
Frequency 50 Hz
Capacity 1.5 hp (1100 W)
Idling speed 2850/min
IP Class IP 20
Tank contents 24litre
Air intake 160 l/min
Max. outlet pressure 8.0 Bar
Weight 24.0 kg
Sound power level 91.0 dB (A)
GB
