Spare parts list DHM-1100
Ferm no. Description Position no.
400480 Stator 4, 5
400481 Armature 10
806201 Bearing 6201 zz 13
806203 Bearing 6203 zz 19
806001 Bearing 6001 zz 22
400482 Gear set 23, 30
806201 Bearing 6201 zz 24
806205 Bearing 6205ZZ 25
400483 Connection rod + crankshaft 26, 27, 36A, 37, 38, 38B
806302 Bearing 6302ZZ 31
400484 O-ring set 41B, 53
400485 Oil Gauge 61
400486 Carbon brush (set) 66
400487 Brush cover complete 67 till 69
400488 Side handle complete 76 ,91A, 92, 93A, 94 till 97
400489 Wrench set 901, 902, 903
400490 Lubricant oiler 904
DEMOLITION HAMMER DRILL DHM-1100
The numbers in the following text correspond with the pictures at page 2
Read this manual carefully, before using the machine. Ensure that you know how
the machine works, and how it should be operated. Maintain the machine in
accordance with the instructions, and make certain that the machine functions
correctly. Store this manual and other enclosed documentation with the machine.
Intended use
The demolition hammer is intended for demolishing concrete, chiseling off concrete, grooving
and bar cutting.
Application examples: installation of piping and wiring, sanitary facility installation, machinery
installation, water supply and drainage work, interior jobs, harbor facilities and other civil
engineering works.
Please inspect the machine and accessories for transit damage.
Contents
1. Machine information
2. Safety instructions
3. Assembly
4. Operating
5. Maintenance
1. MACHINE INFORMATION
Technical specifications
Product information
Fig. 1
1. Switch lock
2. Trigger switch
3. Main handle
4. Cover carbon brush
5. Auxiliary handle
Voltage 230 V
Frequency 50 Hz
Power rating 1100 W
Impact rate 1400/min
Weight 6.7 kg
Lpa (sound pressure level) 88 dB(A)
Lwa (sound power level) 99 dB(A)
Vibration value 5.3 m/s
2
