Spare parts list
HDM1027S -950W
No Description Position
101140 Seal circlet 1
101141 Sleeve 2
101142 Snap ring 3
101143 Holder 4
101144 Spring 5
101167 Function selector set complete 
101168 Needle bearing NK2512 21
 Hammer set 23 to 42
101170 O-ring 15 x 3 44
101171 Cylinder 45
101172 Aluminum base 
101173 Driving set 50 to 56
101174 Needle bearing 0818 57
101175 Sealing rubber 60
101176  65
101177 Rotor with fan 66
101178 Bearing 6072Z 67
 Bearing sleeve 68
101180 Stator 
101163 Carbon brush 74
101181 Carbon brush holder 75, 76
101182 Switch 77
101183 Capacitor 80
101164 Depth limiter 88
410005 Auxilary connect ring set HDM 
410002 Auxilary handle M8 nut 
