6. Collet nut
7. Spindle lock
8. Wing bolt for depth stop
9. Depth stop
10. Clamping lever
11. Plunge depth scale
12. Adjusting wheel for electronic speed control
13. Dust extraction facility
14. Parallel fence
15. Guide rod
16. Depth stop revolver
17. Screws
18. Template guide
19. Dust tube
20. Centre pin
2. SAFETY INSTRUCTIONS
The following symbols are used in these
instructions for use:
Danger of life and risk of injury as well as
risk of damage to the machine in case of
non-adherence to the safety instructions
in these instructions of use.
Danger of electric shock.
Remove the plug from the mains socket.
Variable speed control.
Wear ear and eye protection.
Wear a dust mask.
Wear protection gloves.
Safety instructions for routers
• Hold the power tool by insulated gripping
surfaces only, because the cutter may contact
its own cord. Cutting a “live” wire may make
exposed metal parts of the power tool “live”
and could give the operator an electric shock.
• Use clamps or another practical way to
secure and support the workpiece to a stable
platform. Holding the work by your hand or
against the body leaves it unstable and may
lead to loss of control.
• Please check workpieces for any obstructions
on the surface of the material, such as
protruding nails etc., to protect the router
head.
• Wait until the router has come to a complete
stop before removing any blocked or routed
material around the cutter. Use a long stick for
this and never your finger.
• Please keep your hands away from the routing
surface.
• Immediately switch off the tool if it starts
producing any unusual noise or starts vibrating
excessively.
• Please check that all parts are secure, tools
are removed etc. before operation.
Always check that the power supply
corresponds to the voltage on the rating
plate.
Your machine is double insulated,
therefore no earthwire is required.
• Immediately throw away old cables or plugs
when they have been replaced by new ones. It
is dangerous to insert the plug of a loose cable
in the wall outlet.
• Only use an approved extension cable suitable
for the power input of the machine. The
minimum conductor size is 1.5 mm2. When
using a cable reel always unwind the reel
completely.
Prior to mounting an accessory always
unplug the tool.
Wait until the machine has come to a
complete standstill and the cutter has
cooled down before replacing a cutter.
If the supply cord of this power tool is damaged,
it must be replaced by a specially prepared
supply cord available through the service
organization.
