Ferm
ARC WELDER 40 - 100A
The numbers in the following text refer to the
picture on page 2 + 109
Read the operating instructions
carefully before using this device.
Familiarise yourself with its functions
and basic operation. Service the device
as per the instructions to ensure that it
always functions properly. The
operating instructions and the
accompanying documentation must be
kept in the vicinity of the device.
Introduction
The fusion welding process is used to melt the
workpiece material under the influence of heat
supplied. With electrical arc welding use is also
made of welding material (electrodes). The weld
originates after solidification.
The heat required is obtained by maintaining an
electrical arc between the electrode and
workpiece. The welding process requires a strong
current (40-100 A) with a relatively low voltage
(10-48 V). A transformer in the welding appliance
ensures the lowering of the mains voltage (230 V).
The device is not suitable for commercial use!
Contents
1. Machine information
2. Safety instructions
3. Mounting accessories
4. Operation
5. Service & maintenance
1. Machine information
Technical specifications
Voltage 230 V ~
Frequency 50 Hz
Welding power 40-100 A
Ignition voltage ≤ 48 V
Electrode thickness 1.6 - 2.5 mm
Weight 13.2 kg
Dimensions 290x195x170 mm
Thermal protection 120ºC ± 5ºC
Power cable H07RN-F, 3G x 1.5 mm
2
Welding cable H01N2-D1 x 10 mm
2
Contents of packing
1 Welding appliance
1 Welding mask
1 Wire brush/scaling hammer
1 User Manual
1 Safety instructions
1 Guarantee card
Check the machines, loose parts and accessories
for transport damage.
Product information
Fig. 1
1. Indicator lamp temperature
2. On/off switch
3. Rotary knob for setting current intensity
4. Welding cable with electrode holder
5. Earth cable with fixture
6. Rubber cap
7. Handle
8. Ventilation slots
9. Wire brush /scaling hammer
10. Welding mask
11. Electrodes
Table: setting and use
Ø Electrode (mm) Current intensity (A) Suitable for, among
others:
1.6 45-55 Material thickness ≤ 2 mm
Repairing of moped/bicycle
2 50-75 Material thickness 2-3 mm
Repairing of wall stand
2.5 70-100 Material thickness 4-5 mm
Garden fence, garden toys
3.2 95-150 Material thickness 6-7 mm
Carport, garage
4 130-220 Material thickness 8-12 mm
Construction (heavy)
5 190-250 Material thickness ≥ 12 mm
Construction (very heavy)
2. Safety instructions
Explanation of the symbols
Caution! Read instruction
manual
Denotes risk of personal injury, loss of life
or damage to the tool in case of non-
observance of the instructions in this
manual.
Indicates electrical shock hazard.
