Pag 9
KIT
MEMOKEY 100C
MEMOKEY 100C
KEYPAD MODULE TEST
• Non volatile memory.
• Power supply:
From 9 to15 Vdc or Vac.
• Consumption:
6 mA (stand-by).
600 mA (12 Vac door release on)
• Temperature range: 0 ÷ 70 ºC
• Auxiliary (wildcard) output: This equipment has a free contact auxiliary output to
which a 6 Vdc device may be connected with a maximum current of 300 mA to carry
out several functions. If the equipment to be connected does not comply with these
specifications, a relay must be used (Ref. 2013).
• IP: 34
TECHNICAL FEATURES
Keypad Module
This kit is programmed at the factory with 3 default codes.
The preprogrammed codes are different for each unit, therefore you are the only one
to know them.
You can use this codes to test the equipment operation as well.
To test the code, dial the the one corresponding to the device you want to verify.
BOTH OPEN THE DOOR AND ACTIVATE THE AUXILIARY DEVICE
CODE
ACTION
CODE 1 (*) OPEN THE DOOR
CODE 2 (*) ACTIVATE THE AUXILIARY DEVICE (if any)
CODE 3 (*)
(*) These codes are shown in a sticker in the back side of the panel controller.
