Fermvision FVQ-6030APP - Table of Contents


2

Contents
MonitorDescription......................................................................................................................................................3
DoorStationDescription...............................................................................................................................................4
Addressingthemonitors(Whenusingmorethanonemonitor):................................................................................5
ImpedanceSwitch.........................................................................................................................................................5
ViewingMultipleDoorStationsOnTheMonitor.........................................................................................................6
WiringDiagrams............................................................................................................................................................7
LockWiring..................................................................................................................................................................16
SummaryKeypaddoorstationcodes.........................................................................................................................23
DetailedKeypadCodes...............................................................................................................................................24
Wi‐FiConfiguration.....................................................................................................................................................27

Dimensions
FrontPlate:219.5x120mm(HxW)
BackingBox:203.5x104x46mm(HxWXD)

Makesuretherecessboxiscompletelysealedtopreventwaterpenetration
