Fernox, Forsyth Road, Sheerwater, Woking, Surrey GU21 5RZ
Technical Helpline: +44 (0) 330 100 7750 Email: sales@fernox.com
Fernox Total Filter TF1 is UK UK Patent No. GB2448232. Patent Applied For GB1213773.3A
www.fernox.com
Sealed system Open vented system
How to change the orientation of the
TF1 Compact and TF1 Total Filter
Using a flat end screwdriver
in the recess shown, gently
lever the locking clip into
the ‘unlock’ position.
Pull the inlet/outlet port
approximately 3 mm away
from the body to allow
rotation to the required
position.
Push the inlet/outlet port
back towards the body of
the unit to prevent further
rotation.
Push the locking clip
securely back into the
‘lock’ position.
Flow
Flow Return
Return
Best position
Good position
Flow
Flow Return
Return
Best position
Good position
