Radar Training System, LabVolt Series
5 © Festo Didactic
•
•
•
•
•
•
•
Table of Contents of the Manual(s)
Synthetic-Aperture Radar (SAR) (User Guide) (593946 (54269-E0))
1 Introduction to SAR
2 Hardware Setup
3 SAR Processor Overview
4 System Description
5 System Operation
6 Processing Examples
7 Specifications
Optional Equipment
Qty Description
Model
number
1 B2 Bomber RCS Scale Model _____________________________________________________ 587493 (39208-02)
1 F-117A Stealth Fighter RCS Scale Model ____________________________________________ 587494 (39209-02)
System Specifications
Parameter Value
Operating Frequency 9.4 GHz
Actual Aperture Beamwidth 24°
Range Resolution 15 cm
Azimuth Resolution 6.5 cm at 3 m (equivalent to 1.25° SAR beamwidth)
Descent Angle 25°
Range Swath 90 cm
Processed Area 4 m² (2 m x 2 m)
Basic Radar Training System (Level 1)
8112495 (8097-10)
The Basic Radar Training System is a complete set of hardware,
courseware, and all necessary accessories such as targets and
interconnecting cables that allows the principles of pulse, CW
Doppler, and FM-CW radar systems to be studied.
The Basic Radar Training System consists of a transmitter, a
receiver, three instrumentation modules, an antenna with
pedestal, a target positioning system, and a set of accessories. A
comprehensive student manual and an instructor guide, which
may be ordered separately, are also provided.
Radar echo of a moving target observed on an A-scope display obtained using a
conventional oscilloscope.
An oscilloscope is required for target
echo visualization on an A-scope
display as well as time-domain
observation of signals at outputs and
test points (the Model 797 Dual Trace
Oscilloscope is recommended).
