Festo LabVolt Series - List of Equipment

1
Only one oscilloscope is required to perform the experiments. Please select the right one based on your AC network.
2
A frequency counter is required to perform the experiments.
Radar Training System, LabVolt Series
© Festo Didactic 6
•
•
•
•
•
•
•
•
•
•
•
List of Equipment
Qty Description
Model
number
1 Horn Antenna ___________________________________________________________________ 581847 (9535-00)
1 Power Supply/ Antenna Motor Driver ______________________________________________ 8084743 (9601-20)
1 Radar Synchronizer / Antenna Controller ____________________________________________ 595986 (9602-20)
1 Rotating-Antenna Pedestal _______________________________________________________ 8112383 (9603-10)
1 Radar Antenna __________________________________________________________________ 581936 (9604-00)
1 Dual-Channel Sampler ___________________________________________________________ 595989 (9605-10)
1 Target Positioning System _______________________________________________________ 8121782 (9607-30)
1 Radar Transmitter _______________________________________________________________ 595172 (9620-20)
1 Radar Receiver __________________________________________________________________ 595990 (9621-20)
1 Accessories for 8097-1 __________________________________________________________ 8112515 (9688-00)
List of Manuals
Table of Contents of the Manual(s)
Principles of Radar Systems (Workbook) (580402 (38542-00))
1-1 Basic Principles of Pulsed Radar
1-2 The Range-Delay Relationship
1-3 Radar Antennas
1-4 The Radar Equation
2-1 Pulsed Radar Transmitter and Receiver
2-2 Antenna Driving System
3-1 CW Radar and the Doppler Effect
3-2 Frequency-Modulated CW Radar
4-1 Troubleshooting a CW Radar
4-2 Troubleshooting an FM-CW Radar
4-3 Troubleshooting a Pulsed Radar: The RF Section
Additional Equipment Required to Perform the Exercises
Qty Description
Model
number
1
Dual-Trace Digital Storage Oscilloscope _____________________________________________ 585695 (798-10)
1
1
Frequency Counter (0.1Hz - 2.4 GHz) ______________________________________________ 8112877 (9416-00)
2
System Specifications
Parameter Value
Power Requirement
Current 10 A (for 120V)
Frequency Range 8-10 GHz
Output Power Density at Horn
CW Mode 0.02 mW/cm²
Description
Manual
number
Principles of Radar Systems (Workbook) _______________________________________________ 580402 (38542-00)
Radar Training System (Workbook (Instructor)) _________________________________________ 580405 (38542-10)
