9
Technical data
Cordless drill/screwdriver CDD 9.6 CDD 12
Motor voltage 9.6 V 12 V
Idle-running speed 1. speed 0 - 380 rpm 0 - 380 rpm
2. speed 0 - 1100 rpm 0 - 1100 rpm
Max torque Soft boring (wood) 10 Nm 18 Nm
Hard boring (metal) 26 Nm 30 Nm
Adjustable torque 0.5 - 5 N 1 - 7 Nm
Chuck capacity 1 - 10 mm 1.5 - 13 mm
Max. drill diameter for metal 12 mm 14 mm
Max. drill diameter for wood 20 mm 25 mm
Tool fitting in chuck 1/4" 1/4"
Weight with battery pack 1.8 kg 2.0 kg
Charger MCU 15 EC 60 ECU 45
Supply voltage (input) 220 - 240 V~ 230 - 240 V~ 230 - 240 V~
Line frequency 50/60 Hz 50 Hz 50/60 Hz
Charging voltage (output) 4.8 - 14.4 V (DC) 7.2 - 14.4 V (DC) 7.2 - 14.4 V (DC)
Charging current
Quick charge max. 7.5 A 1.5 A max. 3 A
Compensation charge pulsating app.0.06 A 0.03 A 0,06 A
Charging time for
NiCd 1.2 Ah app. 11 min - -
NiCd 1.4 Ah app. 13 min app. 70 min app. 38 min
NiCd 1.7 Ah app. 16 min app. 85 min app. 42 min
NiCd 2.0 Ah app. 20 min app. 95 min app. 46 min
NiMH 3.0 Ah app. 70 min - app.70 min
Weight 0.9 kg 1.4 kg 0.5 kg
Battery pack BPH 9.6 C BPH 12 C BP 12 C 3,0 MH
Order number 488 437 488 438 489 728
Voltage 9.6 V 12 V 12 V
Cells 8 x 1.2 V, NiCd 10 x 1.2 V, NiCd 10 x 1,2 V, NiMH
Capacity 2.0 Ah 2.0 Ah 3.0 Ah
Temp. range for charging 5 - 45 °C 5 - 45 °C 5 - 45 °C
Monitoring of charge b y m e a n s o f N T C t h e r m i s t o r
Weight 0.5 kg 0.6 kg 0.6 kg
The specified illustrations can be found at the beginning of the operating instructions.
1 Directions for use
The cordless drill/screwdrivers are suitable for
drilling metal, wood, plastic and similar
materials, as well as for fastening and screwing
down of screws with a diameter up to 6 mm.
The chargers have been designed to charge
the battery packs specified under 2.2.
The user will be liable for damage due to
improper use.
For your own safety
Note attached hints on safety measures.
Protect equipment against moisture.
Protect yourself against flying pieces.
When drilling into walls, caution should be
taken of existing gas, electric and water lines.
Do not use the charger if the connecting cable
is damaged.
Do not use defect and damaged battery
packs.
Only use original Festool battery packs. Do
not use spent and recycled battery packs.
The user shall be liable for damages if Festool
original battery packs are not used.
Do not place spent battery packs into fire or
into domestic waste. Attention: Festool
offers an ecological friendly waste disposal
for used battery packs (refer to RECYCLING
OF BATTERY PACKS).
Do not open battery packs.
Do not store battery packs with metal objects
(danger of short circuit).
No metal objects (metal chips) should enter
the charger at the contact points as well as
through the cooling slits into the equipment
(danger of short circuit).
Repairs may only be performed by authorised
technicians.
Cordless drill/screwdriver
Data on noise level: The sound pressure
level calculated according to EN 50144 is less
than 70 dB(A).
Data on vibration: The calculated and
evaluated vibration acceleration according to
EN 50 144 is less than 2.5 m/s².
